TAMIYA 田宮 M05 Ver.II PRO #58593 (M-05)
|
|
|
| 商品貨號： |
58593
|
| 商品品牌： |
TAMIYA 田宮
|
| 市場價格： |
$4780元
|
| 本店售價： |
$4300元
|
| 備 註： |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Product Specifications
| Type |
Detail |
| Scale |
1/10 |
| Construction type |
Assembly kit |
| Terrain use |
On-Road |
| Drive-train |
2WD FWD |
| Drive type |
Gearbox |
| Drive line |
Dog bone |
| Differential type |
Gear |
| Suspension |
Fully independent double wishbone |
| Steering mechanism |
Bell-crank |
| Shock damper |
Oil-filled damper |
| Shock damper material |
Plastic |
| Tire type |
Not included |
| Tire tread |
N/A |
| Body material |
Not included |
| Chassis material |
Plastic |
| Electronic Speed Control (ESC) |
Not included |
| ESC model |
N/A |
| LED Light buckets |
No |
| LED lights |
No |
| Motor |
N/A |
| Bearings |
Shielded ball bearing |
| Adjustable camber |
Fixed |
| Adjustable toe angles |
Front only |
| Adjustable ground clearance |
Yes |
| Adjustable gear ratio |
Yes |
| Adjustable wheelbase |
Yes |
| Adjustable track width |
Fixed |
| Adjustable shock angle |
Fixed |
| Special feature 1 |
New Feature: The chassis is compatible with square-shaped battery packs. |
| Special feature 2 |
New aluminum motor mount designed specifically for the M-05 V.2 chassis. |
| Special feature 3 |
Chassis, D parts (arm stays and damper stays, etc.) and wheels have a Semi-Gloss Black metal-plated finish. |
| Special feature 4 |
The motor is fitted to a newly-designed mount and has been moved 4.5mm closer to the center of the chassis when compared to the original M-05. |
| Special feature 5 |
Improved weight distribution and sharper steering response. |
| Special feature 6 |
New suspension arms: one-piece suspension arms are made from reinforced plastic. |
| Special feature 7 |
New suspension arms have rebound adjustment with the use of a simple set screw. |
| Special feature 8 |
Low Profile Servo Compatibility. |
| Special feature 9 |
The servo attachment position has been shifted 8mm downwards to secure a lower center of gravity. |
| Requires A |
2-channel radio gear & electronic speed control |
| Requires B |
7.2 battery & charger |
| Requires C |
Body set |
| Requires D |
Tires |
此商品不含電子設備，需要自行組裝噴漆
可另外加購遙控設備、電變、電池&充電器、伺服器、噴漆
馬達 車殼 胎+框 需另購
|
